MSR175 Data Logger Shock, Temperature, Humidity, Air Pressure, Light • Acceleration Sensors ±15 g/±200 g • Stores over 2 m Readings • Replaceable Li-SOCI2 Battery, Operating Time 2 Years

MSR175 data logger for shocks and temperature, 2 acceleration sensors ±15 g/±200 g · 1 additional internal temperature, humidity, air pressure, light sensor · stores over 2 million measured values · replaceable battery

Product features MSR175, type 175B54T6H3P5AA5L3:

• High-speed shock logger with 2 internal acceleration sensors
• 3 shock measurement modes: either ±200 g at 6400 Hz or ±200 g at 3200 Hz or ±15 g at 1600 Hz
• 1 additional internal temperature, humidity, pressure and light sensor included; measurement frequency/storage rate every 10 min.
• Installed memory is capable of storing over 2 million measured values
• Setting of limit values
• Replaceable Li-SOCI₂ battery, battery operating time at least 2 years
• Coloured LED for status indication
• MSR175 software package with Dashboard software for easy start-up of the data logger, MSR ReportGenerator for automatic report generation and MSR ShockViewer (basic version) for detailed analysis of shock events

Ideal for long-time monitoring of transports

With its replacable battery, the MSR175 is an ideal logger for long-time monitoring of transports. The two 3-axis acceleration sensors integrated in the MSR175 shock logger have working ranges of ±15 g and ±200 g. They record shocks and jolts at a measurement frequency of up to 6,400 measurements per second. The installed memory of the logger is capable of storing over 2 million measured values, which is sufficient for more than 700 shocks. In addition, the MSR175 data logger measures and records temperature profiles from -20° to +65 °C, humidity, air pressure and light.

Easy-to-use pc software: Start the logger, evaluate the data, save costs

You can start a recording cycle by means of the user-friendly MSR175 Dashboard PC software, which allows you to configure the loggers with just a few mouse clicks. Subsequently, the measured data recorded by the MSR175 data logger can be quickly transferred to a computer via the USB port. A single click on the MSR Report Generator is sufficient to quickly call up a compact, summarised report on the measured data, for example for documentation purposes. For a detailed measured data analysis of the relevant shock events, the MSR ShockViewer analysis software, which is integrated in the MSR175 software package as a free basic version is at your disposal.
